Hoppe Atlanta Upvc Handles
Hoppe handles in the Atlanta range are 92pz sprung 92pz.
Backplate size of 240mm x 30mm they are available in various finishes.
The distance between the fixing screws is 122mm with the bottom screw positioned 27mm below the euro profile cut-out.
They come supplied as a pair complete with spring cassettes, an 8mm square spindle & 2 colour co-ordinated M5 screws to suit door thickness 65-70mm.
Type (3831N) backplate
Centres (PZ): 92mm
Screw centres: 122mm
Base of euro to bottom screw: 27mm
Top screw to spindle: 23mm
Supplied with spindle & screws
Supplied as a pair
